    Product Details:

    Place of Origin: CHINA
    Brand Name: WILLSTRONG
    Certification: ISO9001, ISO14001, OHSAS18001, INTERTEK, SGS, TUV, PSB, etc
    Model Number: CCAC AS-06

    Payment & Shipping Terms:

    Minimum Order Quantity: 20Tons
    Price: US $2,300 to 4,800/ Ton
    Packaging Details: Carton and Woodden Pallet
    Delivery Time: 10-20 Work days
    Payment Terms: T/T, L/C
    Supply Ability: 40Tons/Day
    Contact Now
    Detailed Product Description
    Product Name: Aluminum Coil Panel Thickness: 0.3~10 Mm
    Standard Size: 1220*2440mm Aluminum Alloy: AA1100/AA3003/AA5005/AA5052
    Core Layer: PE/PVDF/FEVE Application: For Roofing, Manufacturer Of ACP, AHP, Etc
    Packing: In Cartons And Pallets Color: Various Color Available
    High Light:

    colored aluminum foil sheets


    painted aluminum coil

    WILLSTRONG color-coated aluminium coil combines all advantages of modern coil-coating technology in our full-automatic production line. we can created pattern like Wood, stone, graphic as you want. The aluminium substrate gets degreased, chemically pre-treated and coated in a single production step which resulting in a high-quality uniform coating reproducible at any time and a material which has been developed for easy processing for a variety of application.

    PVDF(fluorine-carbon) coating


    PVDF(fluorine-carbon) coating :made of fluorine carbon resin, pigment, ester solvent, after high temperature roasting and baking, the paint is solidified to dry film with super weather resistance. PVDF coating also can be classified as traditional PVDF and nanometer PVDF coating.
    A.Traditional PVDF Coating, with KYNAR500 PVDF, two or three times for coating and baking, has good properties of anti-acid, anti-alkali and is durable in atrocious weather and environment, keeping 15 years no unwonted fading. In view of these facts, we recommend this panel applied for external wall cladding.
    B.Nanometer PVDF Coating, which different with traditional PVDF is the clear coating. It contains nanometer element, which can protect panel from pollution, Because nanometer has self-cleaning effect, It easy to get rid of dust and pollution by raining or water.

    Our color Coated Aluminum Coil Characteristics:
    -High temperature resistant
    -Weathering resistant
    - Scrubbing resistant
    - Sound insulation
    - Acid or alkali proof
    - Fireproof
    - Light weight material is easy to construct and install
    - Bright colors
    - Easy molding process,not rusting etc.

    1.Widely used in insulation board
    2.Aluminum curtain wall
    3.Aluminum-magnesium-manganese roofing system
    4.Aluminum ceiling
    5.Acp and many other areas

    Product Application

    Alucosuper prepainting aluminum coil are made from AA3004 mill finish after degreasing, cleansing and passivated layer processing, and currently most advanced and durable coating materials manufactured by KANAR500 and HYLAR5000 seriess of polyvinylidene fluoride (PVDF) resin. The products are finally molded through other secondary operations including cutting, pressing, punching and bending, which can be applied in overall roofs and building coil for wall decoration with a long span and a large area, be used for decorative coil of interior roofs through being cut into small coil, bending and stamping die processing, and be used for energy-saving exterior wall decoration coil bonding with foaming polyurethane or honeycomb aluminum.




    0.21-1.5mm normally, could be custom-made


    for coil: 600mm ~ 1800mm, could be custom-made
    for sheet: 20mm ~ 1650mm, could be custom-made

    Film thickness:

    single-coated 4-20 micron double coated 25-28 micron 3 coated 35-38 micron

    Coating material:


    Colour choose

    customer colours are also avliliable

    RAL colours can ben availiable

    Directly choose colours from alucosuper colour chart


    Basic Info


    Panel Thickness

    3~10 mm

    Standard size


    Aluminum Alloy

    AA1100, AA3003

    Core Layer

    PE, Aluminum honeycomb, fr, corrugated aluminum etc..


    1220mm, 1250mm, 1500mm, 1575mm


    2440mm, 3200mm, 4000mm, 5600mm


    subject to panel thickness

    Surface on front side

    Polyvinylidene Fluoride (PVDF), FEVE, PET

    Color ranges

    refer to WILLSTRONG color chart, or alternative RAL/PANTONE/DULUX color series


    upon requirements

    Back side finishes

    protective coating

    *** Custom specifications are negotiable ***
