| Place of Origin: | China |
| Brand Name: | willstrong |
| Certification: | CSTB, SGS |
| Model Number: | 3341M |
| Minimum Order Quantity: | 600m2 |
|---|---|
| Price: | US$10~US$20/M2 |
| Packaging Details: | Bulk Packing or Wooden Pallets |
| Delivery Time: | 15 working days |
| Supply Ability: | 60,000,000 sqm/year |
| Alloy Type: | 1100, 3003, 5005 | Weight: | 5.5~7.5KG/M3 |
|---|---|---|---|
| Gloss: | 80% | Sample: | Available |
| High Light: | aluminum composite metal panels,mirror finish aluminium sheet |
||
WILLSTRONG® ACM is a kind of sandwich panel and well known as an ideal material for building facade, interior and sign. It is achieved under heat pressure by laminating two thin aluminum skin and non-toxic polyethylene core. The aluminum skin is pre-treated to appear various colors and textures which allow architects a free design space.
Basic Info
| Panel Thickness | 6mm (0.5mm Alu.+ 5.0mm PE +0.5mm Alu.) |
| Standard size | 1220*2440mm |
| Aluminum Alloy | AA1100, AA3003 |
| Core Layer | Halogen-free fire polyethylene (unbreakable) |
| Width | 1220mm, 1250mm, 1500mm, 1575mm |
| Length | 2440mm, 3200mm, 4000mm, 5600mm |
| Weight | 7.40 kgs / m2 |
| Surface on front side | Polyvinylidene Fluoride (PVDF), FEVE |
| Color ranges | refer to WILLSTRONG color chart,or alternative RAL/PANTONE/DULUX color series |
| Glossiness | 30~40% |
| Back side finishes | protective coating |
*** Custom specifications are negotiable ***
Tolerance
| Length | ±3.0mm |
| Width | ±2.0mm |
| Thickness of panel | ±0.2mm for 3 and 4mm thick panel, ±0.3mm for 5 and 6mm thick panel |
| Bow | ≤5.0mm for panel size of 1220x2440mm |
| Squareness | ≤5.0mm/m |
| Edge instraightness | ≤1.0mm/m |
Advantages & Properties
> Light weight but strong rigidity
> Excellent smoothness
> Big sizes
> Easy fabrication and installation
> Machinability
> Easy to make variety shape
> Numerous colors
> Low maintenance
